Smith & Wesson K Frame L Frame Center Pin New Style All Models - 414690000

Smith & Wesson K Frame and L Frame Cylinder Center Pin - Part #414690000

Factory new OEM cylinder center pin designed for new style K Frame and L Frame revolvers. Critical component that secures the cylinder to the crane assembly, ensuring proper alignment and smooth swing-out operation.

⚠️ Important: New Style Models Only

This center pin is designed for newer production K Frame and L Frame models. It is NOT compatible with older/vintage revolvers. This part fits modern K and L Frame revolvers manufactured with updated specifications.

Compatible Frame Sizes:

K Frame: All new style K Frame models including 10, 12, 13, 14, 15, 16, 17, 18, 19, 48, 53, 64, 65, 66, 67, 617, 648 (new production)

L Frame: All new style L Frame models including 581, 586, 619, 620, 681, 686, 696 (new production)

Caliber Compatibility:

K Frame: .22 LR, .38 Special, .357 Magnum, .41 Magnum

L Frame: .38 Special, .357 Magnum, .44 Special

Key Features:

• Factory new OEM component - authentic Smith & Wesson quality
• Designed for new style K and L Frame revolvers
• Precision machined for proper cylinder alignment
• Essential for safe cylinder swing-out and lockup
• Universal fit across new style K and L Frame models
• Ensures smooth cylinder operation

Function:

The center pin is a critical component that secures the cylinder to the crane (yoke) assembly. It ensures proper cylinder alignment, smooth rotation, and reliable lockup. Replace if worn, damaged, or if experiencing cylinder timing or alignment issues.

Installation:

Gunsmith installation recommended. Requires disassembly of cylinder crane mechanism and proper fitting to ensure correct function.

Need Help Identifying Your Model?

Swing out the cylinder and check behind the yoke on the frame for a model number. Model numbers began in 1957-58. Contact us with your serial number and we can help identify the correct parts and verify compatibility with new style specifications.

We specialize in used, new, and new old stock Smith & Wesson double action revolver parts. Contact us for all your S&W part needs!
